Old 12-27-2009, 06:36 PM   #11 (permalink)
Moderate your Moderation.

Join Date: Nov 2008
Location: Troy, Pa.
Posts: 8,919

Pasta - '96 Volkswagen Passat TDi
90 day: 45.22 mpg (US)
Thanks: 1,369
Thanked 430 Times in 353 Posts
Photochop request!!!

Anyone with some skills, make the rear deck of the Geo look more like the rear deck of the EV1.

See how the EV1 slopes down? The Storm is flat!!! I'm thinking about how I can make a "spoiler" to attach to the deck lid that will slope from the window down, but remain flush or even hang over just a smidgen of the trailing edge of the rear deck.

__________________
"┐ʞɐǝɹɟ ɐ ǝɹ,noʎ uǝɥʍ 'ʇı ʇ,usı 'ʎlǝuol s,ʇı"

  Reply With Quote
Alt Today
Popular topics

Other popular topics in this forum...


Old 12-28-2009, 12:47 AM   #12 (permalink)
PokÚmoderator

cfg83's Avatar

Join Date: Dec 2007
Location: Southern California
Posts: 5,864

1999 Saturn SW2 - '99 Saturn SW2 Wagon
Team Saturn
90 day: 40.49 mpg (US)
Thanks: 439
Thanked 528 Times in 355 Posts
Christ -

I couldn't find a good side view of the EV1, so here is an "ok" attempt :



CarloSW2
__________________

What's your EPA MPG? Go Here and find out!
American Solar Energy Society
  Reply With Quote
Old 12-28-2009, 01:30 AM   #13 (permalink)
Moderate your Moderation.

Join Date: Nov 2008
Location: Troy, Pa.
Posts: 8,919

Pasta - '96 Volkswagen Passat TDi
90 day: 45.22 mpg (US)
Thanks: 1,369
Thanked 430 Times in 353 Posts
Carlos -

You see the spoiler in the image of the Storm?

If you remove that, the deck lid is basically flat. If you notice on the EV1, the decklid is sloped, although not as deeply as the rear window, to continue the reduction of the trailing wake. It's kind of like a Kamm shape, I suppose.

What I'm proposing is the use of a ************ to make a wraparound "spoiler" that leads from about 1/3 of the way up the rear window to just past the edge of the deck lid, following that angle.



**************** = Whatever it comes down to being.

Your chop of the EV1 tail is revealing, though. By comparing the C-pillars, we find that the EV1 is slightly longer than the Storm, and the deck line lower, while the window conclusion is in nearly the same place relative to the ground line.

That, of course, means that without serious body work, the Storm won't have the same body treatment, but I can get the basic taper easily enough, though I'll lose part of the rear window visibility.
