what is the Cd of my trike?

Note the back is "behind" the front - so I add the frontal area of the hood plus the frontal area of the "greenhouse" - windows and above.

Any guesses on Cd?

Aero?

under .20????? (I am hoping?????)

Attached Thumbnails
Click image for larger version

Name:	zaa02.jpg
Views:	113
Size:	51.4 KB
ID:	10911   Click image for larger version

Name:	zaa04.jpg
Views:	104
Size:	54.3 KB
ID:	10912
  Reply With Quote
Alt Today
Popular topics

Other popular topics in this forum...


Old 06-03-2012, 11:48 PM   #2 (permalink)
Master EcoModder

kach22i's Avatar

Join Date: Jul 2011
Location: Ann Arbor, Michigan
Posts: 3,907
Thanks: 62
Thanked 2,609 Times in 1,832 Posts
How long have you had this one?
__________________
George
Architect, Artist and Designer of Objects

1977 Porsche 911s Targa
1998 Chevy S-10 Pick-Up truck
1989 Scat II HP Hovercraft

Chin Spoiler:
http://forums.pelicanparts.com/off-t...effective.html

Rear Spoiler Pick Up Truck
http://forums.pelicanparts.com/off-t...xperiment.html

Roof Wing
http://ecomodder.com/forum/showthrea...1-a-19525.html
  Reply With Quote
Old 06-04-2012, 12:22 AM   #3 (permalink)
Master EcoModder

Join Date: Dec 2011
Location: Boise Idaho
Posts: 842
Thanks: 39
Thanked 89 Times in 69 Posts
started it last december - hoped to have it done for the vetter challenge in call, but didn't get it done.

new hope is on the road in the next 2 weeks..... depends on money/time.
  Reply With Quote
Old 06-04-2012, 09:02 AM   #4 (permalink)
Master EcoModder

NeilBlanchard's Avatar

Join Date: May 2008
Location: Maynard, MA Eaarth
Posts: 7,891

Mica Blue - '05 Scion xA RS 2.0
Team Toyota
90 day: 42.48 mpg (US)

Forest - '15 Nissan Leaf S
Team Nissan
90 day: 156.46 mpg (US)

Number 7 - '15 VW e-Golf SEL
TEAM VW AUDI Group
90 day: 155.81 mpg (US)
Thanks: 3,428
Thanked 2,914 Times in 1,827 Posts
Have you tuft tested it? I don't think it will be below 0.25, but it might be close to that -- the front fenders are probably going to have turbulence behind them. Does the cooling air exhaust out behind the front fenders?
__________________
Sincerely, Neil

http://neilblanchard.blogspot.com/
  Reply With Quote
Old 06-04-2012, 09:49 AM   #5 (permalink)
Master EcoModder

kach22i's Avatar

Join Date: Jul 2011
Location: Ann Arbor, Michigan
Posts: 3,907
Thanks: 62
Thanked 2,609 Times in 1,832 Posts
Quote:
Originally Posted by NeilBlanchard View Post
.............. the front fenders are probably going to have turbulence behind them.
That was my first concern, so much so that I assumed this was a found object being finished up for fun.

I've put a big white "X" in where I think infill from the front fenders may help.

Automobile 2 - Odds and Ends pictures by kach22i - Photobucket


Perhaps a NACA inlet would work where the red "X" is.
SDS EM-4: Aircraft


A photo I took last week:
Lingenfelter-2012 pictures by kach22i - Photobucket
__________________
George
Architect, Artist and Designer of Objects

1977 Porsche 911s Targa
1998 Chevy S-10 Pick-Up truck
1989 Scat II HP Hovercraft

Chin Spoiler:
http://forums.pelicanparts.com/off-t...effective.html

Rear Spoiler Pick Up Truck
http://forums.pelicanparts.com/off-t...xperiment.html

Roof Wing
http://ecomodder.com/forum/showthrea...1-a-19525.html
  Reply With Quote
Old 06-04-2012, 11:58 AM   #6 (permalink)
Master EcoModder

Join Date: Dec 2011
Location: Boise Idaho
Posts: 842
Thanks: 39
Thanked 89 Times in 69 Posts
Quote:
Originally Posted by kach22i View Post
That was my first concern, so much so that I assumed this was a found object being finished up for fun.

I[/IMG]
i bet your baby is ugly also.

it is pretty obvious, even to someone as dumb as me, some infill would help things out.

but it sure is nice having doors which open. and windows which go up and down. and the ability to use factory doors off a donor car.

and strangely enough, aesthetics are apparently important if I want to ever sell some of these. the cheese wedge look is not appealing to the ladies.
  Reply With Quote
Old 06-04-2012, 12:56 PM   #7 (permalink)
Master EcoModder

kach22i's Avatar

Join Date: Jul 2011
Location: Ann Arbor, Michigan
Posts: 3,907
Thanks: 62
Thanked 2,609 Times in 1,832 Posts
Quote:
Originally Posted by drmiller100 View Post
i bet your baby is ugly also.
Sorry, I did not mean to sound rude.

I'm sure when it's painted a pretty shiny color it will be much prettier.

The practical aspect of door operation is appreciated.

I did recently photo an Enzo Ferrari which somehow gets away with a similar detail.

Lingenfelter-2012 pictures by kach22i - Photobucket


And the rear vent facing forward is also rather large.




The downside:
Ferrari Enzo
Quote:
The Enzo has an aerodynamic drag coefficient as poor as 0.36, virtually back to the Testarossa era. However, like Formula 1 cars, its emphasis is on downforce and therefore handling. When you have 660 horsepower on tap and 217mph top speed, you know how important downforce is.
In my opinion, you have something closer to large motorcycle faring/cowling. However when compared to most cars, that is still a very low frontal area, so it's probably a wash.

Some positive changes worth considering.
http://s184.photobucket.com/albums/x...%20and%20Ends/
__________________
George
Architect, Artist and Designer of Objects

1977 Porsche 911s Targa
1998 Chevy S-10 Pick-Up truck
1989 Scat II HP Hovercraft

Chin Spoiler:
http://forums.pelicanparts.com/off-t...effective.html

Rear Spoiler Pick Up Truck
http://forums.pelicanparts.com/off-t...xperiment.html

Roof Wing
http://ecomodder.com/forum/showthrea...1-a-19525.html

Last edited by kach22i; 06-04-2012 at 01:16 PM..
  Reply With Quote
Old 06-04-2012, 01:39 PM   #8 (permalink)
Master EcoModder

skyking's Avatar

Join Date: Apr 2011
Location: Tacoma WA
Posts: 1,368

Woody - '96 Dodge Ram 2500 SLT
Team Cummins
90 day: 23.82 mpg (US)

Avion and Woody - '96 Dodge/Avion Ram 2500/5th wheel combo
90 day: 15.1 mpg (US)

TD eye eye eye - '03 Volkswagen Beetle GLS
90 day: 49.05 mpg (US)

Mule - '07 Dodge Ram 3500 ST
Thanks: 723
Thanked 503 Times in 328 Posts
If you want to get anything out of this site I suggest you quit taking things personally.
It would be a piece of cake, so to speak, to fair in the area in question during testing. Reach out the window and close a second panel, etc.
Then you'd know for sure the cost/benefit. I could make it faired off and still use that door and still have it all work if you are interested.
__________________




2007 Dodge Ram 3500 SRW 4x4 with 6MT
2003 TDI Beetle
2002 TDI Beetle

currently parked - 1996 Dodge 2500 Cummins Turbodiesel
Custom cab, auto, 3.55 gears
  Reply With Quote
The Following 2 Users Say Thank You to skyking For This Useful Post:
Sven7 (06-06-2012), t vago (06-04-2012)
Old 06-04-2012, 01:41 PM   #9 (permalink)
Master EcoModder

skyking's Avatar

Join Date: Apr 2011
Location: Tacoma WA
Posts: 1,368

Woody - '96 Dodge Ram 2500 SLT
Team Cummins
90 day: 23.82 mpg (US)

Avion and Woody - '96 Dodge/Avion Ram 2500/5th wheel combo
90 day: 15.1 mpg (US)

TD eye eye eye - '03 Volkswagen Beetle GLS
90 day: 49.05 mpg (US)

Mule - '07 Dodge Ram 3500 ST
Thanks: 723
Thanked 503 Times in 328 Posts
are you going to close in the front wheelwells, Basjoos-style, with a door?
__________________




2007 Dodge Ram 3500 SRW 4x4 with 6MT
2003 TDI Beetle
2002 TDI Beetle

currently parked - 1996 Dodge 2500 Cummins Turbodiesel
Custom cab, auto, 3.55 gears
  Reply With Quote
Old 06-04-2012, 02:09 PM   #10 (permalink)
Master EcoModder

kach22i's Avatar

Join Date: Jul 2011
Location: Ann Arbor, Michigan
Posts: 3,907
Thanks: 62
Thanked 2,609 Times in 1,832 Posts
Quote:
Originally Posted by skyking View Post
are you going to close in the front wheelwells, Basjoos-style, with a door?
I looked it up:
Basjoos Tells All About His "95 MPG" Aerocivic | Autopia | Wired.com


Good question, that would help too.

I do not have true side and plan views of the trike in question, so I cannot overlay a template. However, the rear looks like it could be extended some.
